AlteriomPainlessMesh

📚 Complete Documentation | 📖 API Reference | 🎯 Examples | 📋 Changelog

🌐 Intro to AlteriomPainlessMesh

AlteriomPainlessMesh is a user-friendly library for creating mesh networks with ESP8266 and ESP32 devices. This Alteriom fork extends the original painlessMesh library with specialized packages for IoT sensor networks, device control, and status monitoring.

🎯 Alteriom Extensions

This fork includes specialized packages for structured IoT communication:

Custom Package Types

Core IoT Packages:

• SensorPackage (Type 200) - Environmental data collection

  • Temperature, humidity, pressure monitoring
  • Battery level tracking
  • Sensor ID and timestamp fields
  • Ideal for environmental monitoring and smart agriculture

• StatusPackage (Type 202) - Basic health monitoring

  • Device status flags and uptime
  • Free memory and WiFi strength
  • Firmware version tracking
  • Command response capability for MQTT bridge

• CommandPackage (Type 400) - Device control and automation (COMMAND per mqtt-schema v0.7.2+)

  • Targeted command execution
  • JSON parameter support
  • Command tracking with unique IDs
  • Perfect for remote device control

Advanced Monitoring Packages:

• MetricsPackage (Type 204) - Comprehensive performance metrics (SENSOR_METRICS per mqtt-schema v0.7.2+)

  • CPU usage and processing metrics
  • Memory health (heap, fragmentation, max allocation)
  • Network throughput and packet statistics
  • Response time and latency tracking
  • Connection quality and WiFi RSSI
  • Dashboard-ready data collection

• HealthCheckPackage (Type 605) - Proactive problem detection (MESH_METRICS per mqtt-schema v0.7.2+)

  • Overall health scoring (0-100 for memory, network, performance)
  • Problem flag indicators (16-bit flags for specific issues)
  • Memory leak detection with trend analysis
  • Predictive maintenance (estimated time to failure)
  • Crash tracking and reboot reason codes
  • Actionable recommendations

Mesh Topology & Management:

• MeshNodeListPackage (Type 600) - Node discovery and inventory (MESH_NODE_LIST per mqtt-schema v0.7.2+)

  • List of all mesh nodes with status (offline/online/unreachable)
  • Signal strength (RSSI) for each node
  • Last seen timestamps
  • Supports up to 50 nodes per message

• MeshTopologyPackage (Type 601) - Network topology visualization (MESH_TOPOLOGY per mqtt-schema v0.7.2+)

  • Connection graph with link quality
  • Latency measurements per connection
  • Hop count tracking
  • Root/gateway node identification
  • Supports up to 100 connections per message

• MeshAlertPackage (Type 602) - Network event notifications (MESH_ALERT per mqtt-schema v0.7.2+)

  • Configurable alert types (low memory, node offline, connection lost)
  • Severity levels (info, warning, critical)
  • Metric-based threshold triggering
  • Human-readable alert messages
  • Supports up to 20 alerts per message

• MeshBridgePackage (Type 603) - Protocol bridging (MESH_BRIDGE per mqtt-schema v0.7.2+)

  • Encapsulates native mesh protocol messages
  • Multi-protocol support (painlessMesh, ESP-NOW, BLE-Mesh)
  • Raw payload with signal strength
  • Gateway node identification
  • Enables heterogeneous mesh networks

• EnhancedStatusPackage (Type 604) - Detailed mesh status (MESH_STATUS per mqtt-schema v0.7.2+)

  • Complete mesh statistics (node count, connections, messages)
  • Performance metrics (latency, packet loss, throughput)
  • Alert flags and error reporting
  • Firmware verification with MD5 hash

Bridge Failover & High Availability:

• BridgeStatusPackage (Type 610) - Bridge health monitoring (BRIDGE_STATUS per mqtt-schema v0.7.3+)

  • Internet connectivity status
  • Router signal strength (RSSI)
  • Gateway IP and router channel
  • Heartbeat for failure detection

• BridgeElectionPackage (Type 611) - Automatic failover election (BRIDGE_ELECTION per mqtt-schema v0.7.3+)

  • Router RSSI measurement
  • Node uptime and free memory
  • Distributed consensus protocol
  • RSSI-based winner selection

• BridgeTakeoverPackage (Type 612) - Bridge role announcement (BRIDGE_TAKEOVER per mqtt-schema v0.7.3+)

  • New bridge identification
  • Previous bridge tracking
  • Takeover reason and timestamp
  • Seamless failover notification

• BridgeCoordinationPackage (Type 613) - Multi-bridge coordination (BRIDGE_COORDINATION per mqtt-schema v0.7.3+)

  • Bridge priority levels (1-10)
  • Role assignment (primary/secondary/standby)
  • Peer bridge discovery
  • Load balancing metrics
  • Hot standby redundancy

• NTPTimeSyncPackage (Type 614) - NTP time synchronization (TIME_SYNC_NTP per mqtt-schema v0.7.3+)

  • Unix timestamp from NTP server
  • Accuracy/precision in milliseconds
  • NTP server source identification
  • Mesh-wide time distribution from bridge

All packages provide type-safe serialization, automatic JSON conversion, and mesh-wide broadcasting or targeted messaging. They align with mqtt-schema v0.7.3+ for enterprise IoT integration.

🚀 Advanced Features

Broadcast OTA Distribution

• 📡 98% Network Traffic Reduction for 50+ node meshes
• ⚡ Parallel Firmware Updates - All nodes receive simultaneously
• 🔄 Backward Compatible - Single parameter enables broadcast mode
• 📊 Scales to 100+ Nodes efficiently

MQTT Status Bridge

• 🌉 Professional Monitoring - Grafana, InfluxDB, Prometheus integration
• 📈 Real-Time Topology - Complete mesh visualization over MQTT
• 🎯 Production Ready - Enterprise IoT and commercial deployments
• ⚙️ Fully Configurable - Adjustable intervals and feature toggles

See BRIDGE_TO_INTERNET.md for complete documentation.

🔄 Automatic Bridge Failover

High Availability for Critical Systems

• 🎯 RSSI-Based Election - Best signal strength wins bridge role
• 🔍 Automatic Detection - 60-second failure detection via heartbeats
• ⚡ Fast Failover - 60-70 second typical recovery time
• 🌐 Distributed Consensus - No single coordinator, deterministic winner selection
• 🛡️ Split-Brain Prevention - State machine prevents concurrent elections
• 📊 Tiebreaker Rules - RSSI → Uptime → Memory → Node ID

Use Cases:

• Fish farm alarm systems requiring 24/7 Internet connectivity
• Industrial IoT networks with critical sensor monitoring
• Smart building systems needing continuous cloud connectivity

Example:

// Enable automatic bridge failover
mesh.setRouterCredentials(ROUTER_SSID, ROUTER_PASSWORD);
mesh.enableBridgeFailover(true);
mesh.onBridgeRoleChanged(&bridgeRoleCallback);

void bridgeRoleCallback(bool isBridge, const String& reason) {
  if (isBridge) {
    Serial.printf("🎯 Promoted to bridge: %s\n", reason.c_str());
  }
}

See bridge_failover example for complete documentation.

🌉 Multi-Bridge Coordination (v1.8.2)

Enterprise Load Balancing and Geographic Redundancy

• 🏢 Multiple Simultaneous Bridges - Run 2+ bridges for load distribution
• ⚖️ Smart Load Balancing - Three strategies: Priority-Based, Round-Robin, Best Signal
• 🎯 Priority System - 10-level priority (10=primary, 1=standby)
• 🔄 Hot Standby - Zero-downtime redundancy without failover delays
• 🌍 Geographic Distribution - Bridges in different locations for large areas
• 📊 Traffic Shaping - Route different data types through different bridges
• 🤝 Automatic Coordination - Bridges discover and coordinate automatically

Use Cases:

• Large warehouses/factories with multiple Internet connections
• Geographic distribution across multiple buildings
• Traffic shaping (sensors → Bridge A, commands → Bridge B)
• Load balancing for high-traffic deployments

Example:

// Primary bridge (priority 10)
mesh.initAsBridge(MESH_PREFIX, MESH_PASSWORD,
                  ROUTER_SSID, ROUTER_PASSWORD,
                  &userScheduler, MESH_PORT, 10);

// Configure load balancing strategy
mesh.setBridgeSelectionStrategy(ROUND_ROBIN);

// Monitor bridge coordination
mesh.onBridgeCoordination(&bridgeCoordinationCallback);

See BRIDGE_TO_INTERNET.md for multi-bridge documentation.

📬 Message Queue for Offline Mode (v1.8.2)

Zero Data Loss During Internet Outages

• 🛡️ Priority-Based Queuing - CRITICAL, HIGH, NORMAL, LOW priorities
• 💾 Smart Eviction - CRITICAL messages never dropped, oldest LOW messages dropped first
• 📡 Automatic Online/Offline Detection - Integrates with bridge status monitoring
• 🔄 Auto-Flush When Online - Queued messages sent automatically when Internet restored
• ⚙️ Configurable - Queue size, priorities, callbacks
• 📊 Queue Statistics - Monitor queue usage, drops, flushes
• 🎯 Production Ready - Battle-tested for critical sensor data

Use Cases:

• Fish farms with critical O2 alarms (original Issue #66 use case)
• Industrial sensors that cannot lose data during outages
• Medical monitoring systems requiring guaranteed delivery
• Any system where data loss is unacceptable

Example:

// Enable message queue with max 100 messages
mesh.enableMessageQueue(true);
mesh.setMaxQueueSize(100);

// Queue critical alarm message
String criticalAlarm = "{\"sensor\":\"O2\",\"value\":2.5,\"alarm\":true}";
mesh.queueMessage(criticalAlarm, CRITICAL);

// Set callbacks
mesh.onQueueFull(&queueFullCallback);
mesh.onQueueFlushed(&queueFlushedCallback);

See BRIDGE_TO_INTERNET.md for message queue documentation.

🌐 Shared Gateway Mode (v1.9.0+)

All Nodes as Internet Gateways with Automatic Failover

• 🌍 Universal Internet Access - All nodes connect to the same router and can send to Internet
• 🔄 Instant Failover - Near-instant relay through mesh when local Internet fails
• ⚡ No Single Point of Failure - Any node can serve as gateway, eliminating bridge dependency
• 🎯 Automatic Gateway Election - RSSI-based election determines primary gateway
• 🛡️ Duplicate Prevention - Built-in deduplication prevents multiple deliveries
• 📊 Delivery Confirmation - Acknowledgment system confirms Internet delivery

Use Cases:

• Fish farm monitoring where any node can send critical O₂ alarms
• Industrial sensor networks with redundant Internet paths
• Smart building systems with resilient cloud connectivity
• Remote monitoring stations with shared WiFi infrastructure

Example:

// Initialize all nodes as shared gateways
bool success = mesh.initAsSharedGateway(
    MESH_PREFIX, MESH_PASSWORD,
    ROUTER_SSID, ROUTER_PASSWORD,
    &userScheduler, MESH_PORT
);

// Send data with automatic failover
mesh.sendToInternet(
    "https://api.example.com/data",
    sensorJson,
    [](bool success, uint16_t status, String error) {
        Serial.printf("Delivery: %s\n", success ? "OK" : error.c_str());
    }
);

// Monitor gateway changes
mesh.onGatewayChanged([](uint32_t newGateway) {
    Serial.printf("Primary gateway: %u\n", newGateway);
});

See sharedGateway example for complete documentation.

MQTT Bridge Commands

The MQTT bridge enables bidirectional communication between MQTT brokers and mesh networks:

• Device Control - Send commands from web applications to mesh nodes via MQTT
• Configuration Management - Query and update node configurations remotely
• Status Monitoring - Receive real-time status updates and sensor data via MQTT
• Event Notifications - Track node connections, disconnections, and mesh topology changes

Documentation:

See mqttBridge example for MQTT integration.

Examples:

• 🌉 MQTT Bridge - Gateway bridge with bidirectional MQTT-mesh routing
• 📡 Alteriom Sensor Node - Example node using SensorPackage, CommandPackage, and StatusPackage

🌐 Core Features

The library handles routing and network management automatically, so you can focus on your application. It uses JSON-based messaging and syncs time across all nodes, making it ideal for coordinated behaviour like synchronized light displays or sensor networks reporting to a central node. The original version was forked from easymesh.

True ad-hoc networking

painlessMesh is a true ad-hoc network, meaning that no-planning, central controller, or router is required. Any system of 1 or more nodes will self-organize into fully functional mesh. The maximum size of the mesh is limited (we think) by the amount of memory in the heap that can be allocated to the sub-connections buffer and so should be really quite high.

JSON based

painlessMesh uses JSON objects for all its messaging. There are a couple of reasons for this. First, it makes the code and the messages human readable and painless to understand and second, it makes it painless to integrate painlessMesh with javascript front-ends, web applications, and other apps. Some performance is lost, but I haven’t been running into performance issues yet. Converting to binary messaging would be fairly straight forward if someone wants to contribute.

Wifi & Networking

painlessMesh is designed to be used with Arduino, but it does not use the Arduino WiFi libraries, as we were running into performance issues (primarily latency) with them. Rather the networking is all done using the native esp32 and esp8266 SDK libraries, which are available through the Arduino IDE. Hopefully though, which networking libraries are used won’t matter to most users much as you can just include painlessMesh.h, run the init() and then work the library through the API.

painlessMesh is not IP networking

painlessMesh does not create a TCP/IP network of nodes. Rather each of the nodes is uniquely identified by its 32bit chipId which is retrieved from the esp8266/esp32 using the system_get_chip_id() call in the SDK. Every node will have a unique number. Messages can either be broadcast to all the nodes on the mesh, or sent specifically to an individual node which is identified by its `nodeId.

Limitations and caveats

• Try to avoid using delay() in your code. To maintain the mesh we need to perform some tasks in the background. Using delay() will stop these tasks from happening and can cause the mesh to lose stability/fall apart. Instead, we recommend using TaskScheduler which is used in painlessMesh itself. Documentation can be found here. For other examples on how to use the scheduler see the example folder.
• painlessMesh subscribes to WiFi events. Please be aware that as a result painlessMesh can be incompatible with user programs/other libraries that try to bind to the same events.
• Try to be conservative in the number of messages (and especially broadcast messages) you sent per minute. This is to prevent the hardware from overloading. Both esp8266 and esp32 are limited in processing power/memory, making it easy to overload the mesh and destabilize it. And while painlessMesh tries to prevent this from happening, it is not always possible to do so.
• Messages can go missing or be dropped due to high traffic and you can not rely on all messages to be delivered. One suggestion to work around is to resend messages every so often. Even if some go missing, most should go through. Another option is to have your nodes send replies when they receive a message. The sending nodes can the resend the message if they haven’t gotten a reply in a certain amount of time.

Installation

Arduino Library Manager

Once registered, installation will be available via Arduino IDE:

1. Open Arduino IDE
2. Go to Tools → Manage Libraries...
3. Search for "AlteriomPainlessMesh"
4. Click Install

The library includes the header file AlteriomPainlessMesh.h which provides access to both the core painlessMesh functionality and Alteriom-specific extensions.

Manual Installation (Current Method)

Option 1: Download ZIP from GitHub Release

1. Go to Releases
2. Download the latest release ZIP file
3. In Arduino IDE: Sketch → Include Library → Add .ZIP Library...
4. Select the downloaded ZIP file
5. Restart Arduino IDE

Option 2: Git Clone

cd ~/Arduino/libraries/
git clone https://github.com/Alteriom/painlessMesh.git AlteriomPainlessMesh
# Restart Arduino IDE

PlatformIO

painlessMesh is included in both the Arduino Library Manager and the platformio library registry and can easily be installed via either of those methods.

Dependencies

painlessMesh makes use of the following libraries, which can be installed through the Arduino Library Manager

• ArduinoJson
• TaskScheduler
• ESPAsyncTCP (ESP8266)
• AsyncTCP (ESP32) - v3.3.0+ required for ESP32-C6

If platformio is used to install the library, then the dependencies will be installed automatically.

Quick Start with Alteriom Packages

Basic Sensor Node

#include "painlessMesh.h"
#include "examples/alteriom/alteriom_sensor_package.hpp"

using namespace alteriom;

#define MESH_PREFIX     "AlteriomMesh"
#define MESH_PASSWORD   "your_password"
#define MESH_PORT       5555

Scheduler userScheduler;
painlessMesh mesh;

void setup() {
    Serial.begin(115200);
    mesh.init(MESH_PREFIX, MESH_PASSWORD, &userScheduler, MESH_PORT);
    mesh.onReceive(&receivedCallback);
}

void loop() {
    mesh.update();

    // Create and send sensor data
    SensorPackage sensor;
    sensor.temperature = 25.5;
    sensor.humidity = 60.0;
    sensor.sensorId = mesh.getNodeId();
    sensor.timestamp = mesh.getNodeTime();

    mesh.sendBroadcast(sensor.toJsonString());
    delay(30000); // Send every 30 seconds
}

void receivedCallback(uint32_t from, String& msg) {
    JsonDocument doc;  // ArduinoJson v7
    deserializeJson(doc, msg);

    if (doc["type"] == 200) { // SensorPackage
        SensorPackage sensor(doc.as<JsonObject>());
        Serial.printf("Sensor %u: %.1f°C, %.1f%% RH\n",
                     sensor.sensorId, sensor.temperature, sensor.humidity);
    }
}

Bridge to Internet (Auto Channel Detection)

The new bridge-centric architecture makes it easy to connect your mesh to the Internet via a router. The bridge node automatically detects the router's channel and configures the mesh accordingly.

Bridge Node

#include "painlessMesh.h"

#define MESH_PREFIX     "MyMeshNetwork"
#define MESH_PASSWORD   "somethingSneaky"
#define ROUTER_SSID     "YourRouterSSID"
#define ROUTER_PASSWORD "YourRouterPassword"

Scheduler userScheduler;
painlessMesh mesh;

void setup() {
  Serial.begin(115200);
  mesh.setDebugMsgTypes(ERROR | STARTUP | CONNECTION);

  // Single call does everything:
  // 1. Connects to router and detects its channel
  // 2. Initializes mesh on detected channel
  // 3. Sets node as root/bridge
  mesh.initAsBridge(MESH_PREFIX, MESH_PASSWORD,
                    ROUTER_SSID, ROUTER_PASSWORD,
                    &userScheduler, 5555);

  mesh.onReceive(&receivedCallback);
}

void loop() { mesh.update(); }

void receivedCallback(uint32_t from, String& msg) {
  // Forward mesh data to Internet services (MQTT, HTTP, etc.)
}

Regular Nodes (Auto Channel Detection)

void setup() {
  Serial.begin(115200);

  // channel=0 means auto-detect the mesh channel
  mesh.init(MESH_PREFIX, MESH_PASSWORD, &userScheduler, 5555,
            WIFI_AP_STA, 0);

  mesh.onReceive(&receivedCallback);
}

See BRIDGE_TO_INTERNET.md for complete documentation.

Message Types

painlessMesh uses two categories of message types:

Protocol-Level Types (Internal Mesh Operations)

These types are used internally by painlessMesh for mesh management and are handled automatically:

Note: These protocol types are managed automatically by painlessMesh and are not typically used in application code.

Application-Level Package Types

These are the message types used by applications built on painlessMesh:

Key Features

Core Features

• 🔄 Automatic Mesh Formation - Nodes discover and connect automatically
• 📡 Self-Healing Network - Adapts when nodes join/leave
• ⏰ Time Synchronization - Coordinated actions across all nodes
• 🔀 Smart Routing - Broadcast, point-to-point, and neighbor messaging
• 🔌 Plugin System - Type-safe custom message packages
• 📱 ESP32 & ESP8266 - Full support for both platforms
• 🛡️ Memory Efficient - Optimized for resource-constrained devices

Advanced Features

• 📡 Broadcast OTA - Efficient firmware distribution for large meshes (50-100+ nodes)
• 🌉 MQTT Bridge - Professional monitoring with Grafana/InfluxDB/Prometheus
• 📊 Topology Visualization - D3.js, Cytoscape.js, Node-RED examples
• 🎯 Production Ready - Enterprise-grade stability and performance
• 🔄 Automatic Bridge Failover - RSSI-based election for high availability
• 🌐 Multi-Bridge Coordination - Load balancing and geographic redundancy
• 💾 Message Queueing - Zero data loss during Internet outages

Examples & Use Cases

• IoT Sensor Networks - Environmental monitoring, smart agriculture
• Home Automation - Distributed lighting, HVAC control
• Industrial Monitoring - Equipment status, predictive maintenance
• Event Coordination - Synchronized displays, distributed processing
• Bridge Networks - Connect mesh to WiFi/Internet/MQTT - 📖 Bridge Guide

Latest Release: v1.9.17 (December 21, 2025)

Documentation Enhancement & Package Organization

• 📚 Production-Level Documentation - Removed phase terminology for clearer product positioning
• 📦 Complete Package Catalog - All 19 application-level package types documented in numerical order
• 🎯 Enhanced Feature Clarity - Improved Advanced Features section with comprehensive capability list
• ✨ Professional Quality - Documentation suitable for enterprise adoption and production deployments

Recent Key Features (v1.9.0 - v1.9.16):

• 🔍 Mesh Connectivity Detection - New hasActiveMeshConnections() and getLastKnownBridge() APIs
• 🌉 Improved Bridge Detection - getPrimaryBridge() returns last known bridge when disconnected
• ⚡ Enhanced TCP Reliability - Exponential backoff and increased retries for mesh connections
• 🛡️ Race Condition Fixes - Improved bridge status and connection validation
• 📦 Consolidated Examples - Streamlined to 14 essential examples
• ⚙️ Configurable Election Timing - Prevent split-brain with setElectionStartupDelay() and setElectionRandomDelay()

📋 Full CHANGELOG

Getting Help

• FAQ - Common questions and solutions
• Common Issues - Troubleshooting guide
• GitHub Issues - Bug reports and feature requests
• Community Forum - Community support
• API Documentation - Generated API docs

Development

Building from Source

git clone https://github.com/Alteriom/painlessMesh.git
cd painlessMesh
git submodule update --init
cmake -G Ninja .
ninja
run-parts --regex catch_ bin/  # Run tests

Requirements

• ESP32/ESP8266: Arduino Core 2.0.0+
• Dependencies: ArduinoJson 7.x, TaskScheduler 4.x
• Development: CMake, Ninja, Boost (for desktop testing)

Testing Bridge/Internet Functionality

painlessMesh includes a Mock HTTP Server for testing sendToInternet() functionality without requiring actual Internet connectivity. This enables:

• 🚀 Fast testing cycles - Instant responses instead of waiting for external APIs
• 🔧 Offline development - No Internet connection required
• ✅ Reproducible scenarios - Control all test conditions precisely
• 🤖 CI/CD automation - Automated testing in pipelines

# Start mock server
cd test/mock-http-server
python3 server.py

# Test various HTTP scenarios
curl http://localhost:8080/status/200     # Success
curl http://localhost:8080/status/404     # Not Found
curl http://localhost:8080/whatsapp?...   # WhatsApp API simulation

See Mock HTTP Server Documentation for complete usage guide.

CI/CD Pipeline

painlessMesh features a state-of-the-art automated CI/CD pipeline:

🔄 Continuous Integration:

• Automated builds on gcc/clang with strict warnings
• Cross-platform testing (Arduino CLI, PlatformIO)
• Code quality and formatting validation
• Comprehensive test suite execution

🚀 Automated Releases:

• Semantic versioning with automated tagging
• GitHub Releases with changelog generation
• Library package distribution
• Documentation deployment to GitHub Pages
• Arduino Library Manager & PlatformIO Registry integration

📋 Release Management:

# Bump version and prepare release
./scripts/bump-version.sh patch  # or minor, major
./scripts/validate-release.sh    # Validate release readiness

# Edit CHANGELOG.md, then commit with release prefix
git commit -am "release: v1.5.7"
git push origin main  # Triggers automated release

See RELEASE_GUIDE.md for complete release documentation.

Contributing

We try to follow the git flow development model. Which means that we have a develop branch and main branch. All development is done under feature branches, which are (when finished) merged into the development branch. When a new version is released we merge the develop branch into the main branch. For more details see the CONTRIBUTING.md file.

Funding

If you like the library please consider supporting its development. Your contributions help me spend more time improving painlessMesh.

Donate via PayPal • dominic.lavoie@gmail.com

📚 Documentation

📖 Essential Guides

🚀 Quick Links

New to AlteriomPainlessMesh?

• Quick Start - Get your first mesh running in 5 minutes
• Installation - Arduino IDE and PlatformIO setup
• First Mesh - Build a multi-node network

Reference Documentation:

• Core API - painlessMesh class methods
• Alteriom Extensions - SensorPackage, CommandPackage, StatusPackage
• Examples - 16 working examples for common scenarios

Need Help?

• FAQ - Frequently asked questions
• Common Issues - Troubleshooting guide
• GitHub Issues - Bug reports and support

🔧 Quick API Reference

Core Methods:

#include "painlessMesh.h"

painlessMesh mesh;

// Initialize mesh
mesh.init(MESH_PREFIX, MESH_PASSWORD, &userScheduler, MESH_PORT);

// Main loop - call this in loop()
mesh.update();

// Send messages
mesh.sendBroadcast("Hello everyone!");
mesh.sendSingle(nodeId, "Hello specific node");

// Get information
uint32_t myId = mesh.getNodeId();
std::list<uint32_t> nodes = mesh.getNodeList();

// Register callbacks
mesh.onReceive(&receivedCallback);
mesh.onNewConnection(&newConnectionCallback);
mesh.onChangedConnections(&changedConnectionCallback);

// Debug configuration
mesh.setDebugMsgTypes(ERROR | STARTUP | CONNECTION);

For complete API documentation, see USER_GUIDE.md or online docs.

Funding

Most development of painlessMesh has been done as a hobby, but some specific features have been funded by the companies listed below:

Sowillo
