tldraw-mcp
Minimal MCP server for editing tldraw .tldr files via JSON manipulation. Headless, no browser needed.
Status
Working skeleton. Schema validation is wired (@tldraw/tlschema validators run before every write), fractional indexing uses @tldraw/utils, file writes are guarded by proper-lockfile. Output verified end-to-end against the real tldraw runtime via Store.loadStoreSnapshot() in the contract test layer.
Quick Start
Requires Node ≥ 20.
1. Install (user scope — available in every project):
claude mcp remove tldraw-m9810223 -s user 2>/dev/null; rm -rf ~/.npm/_npx
claude mcp add -s user tldraw-m9810223 -- npx -y github:m9810223/tldraw-mcp
Restart Claude Code. /mcp should now list tldraw-m9810223.
2. Try the demo prompt in Claude Code:
Draw the Shai-Hulud supply-chain attack flow described in this article with MCP `tldraw-m9810223`, save to `./demo.tldr`:
https://semgrep.dev/blog/2026/malicious-dependency-in-pytorch-lightning-used-for-ai-training/
- Match the actors and how data/control flows between them
- Polish the result at the end
3. View the result — drop ./demo.tldr onto tldraw.com, or use the tldraw VS Code extension for live preview.
Source file: docs/demo.tldr
Tools
File / page lifecycle
| Tool | What it does |
|---|---|
create_empty_file | Create a fresh .tldr with a default page |
create_page | Add a new page |
list_pages | List pages with id, name, ordering index |
move_to_page | Move shapes; bindings: 'error' | 'pull' | 'cut' controls binding handling |
Shapes
| Tool | What it does |
|---|---|
create_rect | Create a rectangle (geo shape) |
create_text | Create a text shape |
create_group | Group shapes by reparenting them |
ungroup | Dissolve a group, reparenting its children to the group's parent |
connect | Arrow + bindings between two same-page shapes |
list_shapes | List shapes — id, type, x, y, label only |
get_shape | Full record of one shape by id |
update_shape | Shallow-merge patch (use nested { "props": {...} } for prop edits) |
delete_shape | Delete by id; cascade: true (default) also removes attached arrows + bindings |
Layout / text fitting
| Tool | What it does |
|---|---|
fit_to_text | Resize a geo/text shape to fit its current text content |
align | Align shapes on an axis (left/right/top/bottom/center-x/center-y) |
distribute | Even-space shapes between the outermost two |
auto_layout | Lay shapes out in a horizontal/vertical chain |
graph_layout | Dagre layout for arrow-connected shapes (best for non-chain topologies) |
measure_arrow_labels | Report label sizes + endpoint distances for labeled arrows |
bend_overlapping_arrows | Bend parallel arrows (same shape pair) symmetrically; priority[] keeps important arrows straight. graph_layout calls this automatically. |
polish_layout | One-shot finisher: fit_to_text every node + graph_layout (auto-bends arrows). Use as the last step after building a fresh diagram. |
Discovery & escape hatch
| Tool | What it does | Token cost |
|---|---|---|
search_api | List supported shape types + curated required props. Pass {type, verbose:true} to dump live prop names from @tldraw/tlschema for any type (including ones not in the curated list) | low / medium |
exec_jq | Run a jq filter against the file. write=true persists (auto-checkpoint first) | varies |
Checkpoints (safety)
| Tool | What it does | Token cost |
|---|---|---|
save_checkpoint | Copy .tldr to a timestamped backup | low |
list_checkpoints | List backups, newest first | low |
restore_checkpoint | Restore a backup (most recent if checkpoint omitted) | low |
The token-saving design: tools take primitive args, return ids or ok. The full JSON only enters context when you call get_shape deliberately.
Install / Update / Remove
jq only needed for exec_jq (brew install jq / apt-get install jq).
# Install — user scope: every project on this machine (recommended)
claude mcp remove tldraw-m9810223 -s user 2>/dev/null; rm -rf ~/.npm/_npx
claude mcp add -s user tldraw-m9810223 -- npx -y github:m9810223/tldraw-mcp
# Install — local scope (default): only the current project directory
claude mcp remove tldraw-m9810223 2>/dev/null; rm -rf ~/.npm/_npx
claude mcp add tldraw-m9810223 -- npx -y github:m9810223/tldraw-mcp
The first arg (tldraw-m9810223) is the local server name — pick whatever you like, then refer to it the same way in subsequent commands. Restart Claude Code, then /mcp lists it with 26 tools.
Wire up to other MCP clients
Same JSON shape, different config file location:
| Client | Config path |
|---|---|
| Claude Desktop | ~/Library/Application Support/Claude/claude_desktop_config.json (macOS) |
| Cursor | ~/.cursor/mcp.json |
| VS Code | .vscode/mcp.json |
Bootstrapping a .tldr file
Use the create_empty_file tool, or save an empty canvas from tldraw.com and point tools at the absolute path.
create_empty_file({ file: "/tmp/demo.tldr" })
Viewing / editing the output
| Tool | Notes |
|---|---|
| tldraw.com | Drag the .tldr file onto the page |
| tldraw VS Code extension | Native .tldr preview + edit inside VS Code; survives file changes from the MCP server |
| Tldraw Desktop / official editor | Drop the file in |
The VS Code extension is the smoothest dev loop — keep code path/to/file.tldr open in a tab while the MCP edits it; the editor refreshes on disk change.
Design comparison vs official tldraw-mcp-app
The Cloudflare-hosted official MCP exposes only search + exec (run any JS in a live tldraw Editor). This skeleton goes the opposite way — typed JSON edits over .tldr files — and borrows the discovery pattern (search_api) and escape hatch (exec_jq) so an LLM can fall through when typed tools don't cover an operation.
Official tldraw-mcp-app | This skeleton | |
|---|---|---|
| Transport | streamable-http + sse (Cloudflare) | stdio (works in Claude Code directly) |
| Runtime | Real tldraw Editor in widget iframe | Pure Node, edits raw JSON |
| Tools | 2 (search, exec) + checkpoints | 26: file/page (4) + shape (9) + layout (8) + discovery (2) + ckpt (3) |
| Live preview | Yes (widget iframe) | No (open the file in tldraw to view) |
| Coverage | Whole Editor API | Geo / text / arrow + jq escape hatch |
Known gaps
index(z-order) only supports appending above the current max — no insert-between- No image / video / asset support
- Schema version pinning is informational only — opening a file in a newer tldraw may trigger migrations
search_apicurated list is hand-maintained alongside the live@tldraw/tlschemareflection
Architecture
src/
index.ts MCP server entry, tool registration (stdio transport)
tools.ts Tool handlers + zod input schemas
shapes.ts tldraw record factories (geo/text/arrow/group/binding)
store.ts Load/save .tldr + withFileLock; helpers (id gen, indexing, find, page-of-shape, bindings-for-shape)
template.ts Empty .tldr generator using @tldraw/tlschema serialize()
validate.ts validateShape / validateBinding using createShapeValidator + createBindingValidator
checkpoint.ts Timestamped backups under .tldraw-mcp-checkpoints/
jq.ts Shell-out to jq for the exec_jq escape hatch
text-metrics.ts Text size heuristics for autoFit + label measurement
graph-layout.ts Dagre wrapper for graph_layout
arrow-bending.ts Detect parallel-edge overlap + assign symmetric bend values
test/
unit/ store + validate + text-metrics + arrow-bending (34 tests)
integration/ tools end-to-end on tmp .tldr (39 tests)
contract/ loadStoreSnapshot against real @tldraw/store (4 tests)
boundary/ N-1 / N / N+1 limits + concurrent writes (89 tests)
Pure JSON manipulation — no @tldraw/store, no DOM, no React.
